Wall Mount 40kW Public Electric Charging Points IP54 200V-1000V

Brand Name : ARK

Model Number : UF160K750CJ-AC22

Certification : CE

Place of Origin : China

MOQ : 1 Unit

Price : Negotiable

Payment Terms : T/T

Supply Ability : 1000 units per month

Delivery Time : 6-8 weeks

Packaging Details : Wooden case package 1830 x 971 x 710mm Power modules outside the charger cabinet to be shipped to avoid the damage during shipping. 32 units per 40' Container

Input Voltage Range : 400Vac +/-10%, 3-phase

Input Frequency Range : 50Hz/60Hz

Output Voltage Range : 200 - 1000V DC constant output @ above 300V, 400V AC

Output Current Range : 0-133A

Warranty : 2 Years

Working Humidity : 5%-95%

Working Temperature : -30° C to +55° C

Charging Standards : CCS Combo-2 & CHAdeMO

Material : Steel

Contact Now

Wall Mount 40kW Public Electric Charging Points IP54 200V-1000V

ARK hig power output 200-1000V IP54 CCS and CHAdeMO charging station for electric car is the most advanced Electric Vehicle Charging Station currently available. Its modular design allows for free configuration of power modules and electrical components - increase the output power from 20kW to 40kW or even higher, application of a Ethernet/WiFi/3g/4g communication or RFID card reader. This series chargers can be connected to OCPP backend for customers to monitor and manage.



EV Charging Station Product Parameters

Specification	Model	EF040CJ040
Structure	Dimension (H x W x D)	600 x 700 x 363mm
	Installation method	Wall mount
	Cable routing	Bottom inlet, top outlet wiring
	Charging standard	CCS combo-1/2, CHAdeMO
	Cable length	5m
	Outlet number	2
Electrical specifications	Input voltage	400Vac +/-10%, 3-phase
	Input frequency	50Hz/60Hz
	Rated power	20kW/40kW
	Output voltage range	200 – 1000V DC constant output @ above 300V
	Output current range	0-133A DC
	Efficiency	> 94% at rated output
Function	Charging type	Mode4
	User Interface	RFID, 7” touch screen, Emergency button
	Cellular	LTE modem, GPRS/3G/4G
	Communication	CAN, PLC, PWM, OCPP 1.6 JSON
	Working humidity	5% – 95% non-condensation
	Protection grade IP54	IP54
	Safety standard	IEC 61851-1,IEC 61851-22,IEC 61851-23,
	Safety standard	IEC 61851-24, DIN 70121,IEC 15118-3

FAQ:

Q1: Are you Trading Company or manufacturer?

A: We are professional manufacturer with R&D team.

Q2: What are your main market?

A: Europe, North America and Southeast Asia.

Q3: How long does it take to produce a sample?

A: Normally we have stocks for sampler service. If not, it takes about 40 days to produce a new sample.

Q4: What is the lead time?

A: The lead time is 40 to 45 days, it depends on the quantity you order.

Q5: What is the payment term?

A: T/T and L/C at sight.

Q6: Why is new model expensive than other old models?

A: A new model needs large R&D and mould cost, and the depletion rate is bigger during mould and production. Besides, new model is low productive but labor costs keep same as old model.

Our Service:

1. We will reply your inquiry in 24 hours.

2. T/T and L/C payment accepted.

3. Shipping by air, by sea, by express (DHL,Fedex and etc).

4. Warranty: 24 months after shipment.

5. Remote technical service and support.

6. Customized service according to the customer's requirement.

Product Tags:

ARK 400A public electric charging points

ARK 200A public electric charging points

ARK IP54 public car charging stations

Wall Mount 40kW Public Electric Charging Points IP54 200V-1000V Images
